Wired White Jade Road Stud
Key Features:
Power and control data transmission by wire
Light-emitting modules embedded inside PC shell, IP68
LEDs protected against chemical and mechanical impacts
Spot lighting
Polycarbonate epoxy filler
105x100x20mm
0.30kg
Red blue green yellow white
IP 68
Power and control data transmission by wire
Light-emitting modules embedded inside PC shell, IP68
LEDs protected against chemical and mechanical impacts
Spot lighting
Polycarbonate epoxy filler
105x100x20mm
0.30kg
Red blue green yellow white
IP 68
-
-
Size105x100x20mm
-
Net Weight0.30kg
-
MaterialPC shell with epoxy filler
-
LEDφ8mm, one-way 6pcs , two-way 12pcs;φ8mm,42 pcs (Side 2*6 pcs + Front 30pcs)
-
LED Working ModeSteady or Flash (controller)
-
Average Light Intensity>100cd,(white>100 cd,red,yellow,blue,green >35cd)
-
View distanceover 500m
-
ColorRed/Yellow/White/Blue/Green
-
Permissible Operating VoltageDC 12-24V
-
Power Consumption0.5 W 50ma
-
Service Life of LEDs100,000 hours acc. to manufacturer's data
-
LED Opening Angle+/- 7.5°
-
Connection TechnologyT-Connection or serial connection
-
InstallationScrews or 2-component adhesives
-
Compression resistanceover 10 tons
-
Working temperature-20℃~+70℃
-
Ingress ProtectionIP68
-
WarrantyOne year
-
-
Application:
Road Tunnels
Highways
Country Roads
Parking Lots
Industrial Sites
Stadiums
Airports
-
